TELESCOBIC PROPS SYSTEM-667

Product Code: TELESKOBIK DIKMELI SISTEM

Ease of erection and dismantling process provides faster circulation at the construction site. System can be used for all types of slabs. Storing and stacking is efortless. Can be used for up to 6 m heights. As the components of the system
have high load bearing capacity, simple and speedy erection is possible with less components. System props can be easily adjusted for various heights. System is very useful in projects with typical heights. System provides ease of circulation in all kinds of projects with less components. It is costeffective and longlasting compared to conventional formworks. Tubes; external tube dia 60x2.5 mm, internal tube dia48x3 mm, made of TSE certified standart tube. There is no usage of the waste tubes. All tubes subjected to pressure test. Tubes have the same wall thickness at all crosssections.

Mechanism is made of dia60x4 mm tube which prevents stripping of the nut. Nut; CE certified nodular casted high quality product. Base Plate; Made from 150x150x5 mm sheetiron. It has a special form to prevent the curling of the base plate from sides under heavy load. Welding; Making the circular welding by the automatic welding robots without touch of human hand prevents the workmanship faults. Drilling; By the usage of the special drilling machine, drilling process is being done without any deformation and no weak spot coming up during drilling process. All telescopic props subjected to mechanical testing in KOSGEB laboratories and permissible load bearing capacity of the props certified as 25KN.
