Thermoform Vacuum / MAP Packaging Machine for Fresh Cut Fruits and Vegetables-46124
Product Code: CM7
CEHUMA CM series thermoformers are basically for automatic vacuum and MAP (modified atmosphere packaging) applications and very often used in dairy, meat, poultry, seafood, dried fruits and vegetables, bakery, medical and so on. The machine is chain driven type which means the plastic film material forward movement is done by the gripper chain system. Further, CM series are suitable for processing of both the flexible and rigid plastic films up to a width of 600 mm and a thickness of 1200μm.
Fresh-cut fruits and vegetables are the type of food which is processed minimally or slightly offer consumers ready-to-eat/use fruit and vegetable products. They are convenient, healthful, and in a fresh-like state. Processing of fresh-cut produce involves sorting, cleaning, washing, trimming/peeling/deseeding/coring, and cutting . Fresh-cut fruits and vegetables are the most rapidly growing convenient food category in history.
The success of fresh-cut fruit and vegetable products in the marketplace has been made possible by modified atmosphere packaging (MAP) innovations. MAP is a
packaging technology that modifies the gas composition around the products in food packages from normal air to provide an atmosphere for increasing the shelf life and maintaining the quality of the food.
As Fresh cut fruits and vegetables has a fast respiration rate which leads to rapid deterioration packaging plays a key role for keeping the fresh cut fruits and vegetables at the shelves for a long period of time. This is where CEHUMA comes into mind as Cehuma offers its CM series for vacuum and modified atmosphere packing of fresh-cut fruits and vegetables at a superior quality.
Technical Specifications
• Capacity (Cyc/min) | 5-12
• Web Width (mm) | 180-600
• Bottom Web Material | Flexible/Rigid
• Top Web Material | Pa+Pe/AL/Tyvek
• Machine Length (mm) | 3500-9500
• Forming Depth (mm) | 60-150
• Energy Consumption (kW) | 8-38
• Electric Suppy (3x380V. 50 Hz)
• Air Pressure (Bar) | 6-8
• Cooling Water (C) | 10-16
Advantages
• Corrosion-Resistant Gripper Chain
• Entire Stainless Steel Structure
• Modular Construction
• Programmable Advance Speed
• Multi-Language Selection
• Safety Standards According to "EC" Regulations
• Large Touch Screen
Options
• Flexible / Rigid Film
• Vacuum / MAP (modified atmosphere packaging) Application
• Dosing and Product Loading Systems
• Coding and Printing Systems
• Metal Dedectors / Check Weighers
• IP65 Level of Protection
• Printed Film Registration Top Film
