VISPO SLIDING BALCONY GLAZING SYSTEM-28161

Product Code: VISPO

• Easy installation
• Aesthetic & one-piece appearance
• Sound insulation performance
• Reduces energy consumption with the thermal insulation it provides
• Easy cleaning
• Reduced hand contact with glass with self-handle profile
• Large viewing area with minimal framing
• Smooth operating system

Windproof system design and equipment
• Prevents direct air passage
• Registered design

Technical Specifications
• 4 track bottom-frame with 117 mm width
• Standard or low threshold options
o Standard threshold - 14 mm
o Low threshold - 9 mm
• Easy water drainage with inclined design with standard threshold
• Cleaner interior with pile weather seal applied at the bottom of the sash
• Vent height up to 2.200 mm
• Vent width up to 108 mm
• Up to 6.500 mm wide application with 8 vents (4 to 4)
• 1.quality T6 thermal processed 6063 alloy aluminum
• 10 - 12 µm anodizing thickness
• 60 -80 µm coating thickness

Hardware

• Roller
o Special polyamide plastic with 49 mm. diameter
o Solid and rigid body structure
o Galvanized steel to increase corrosion resistance

• Locking
o Ergonomic and easy locking
o Locking with concealed door handle

• Glass Applications
o 8 mm tempered glass
o Clear view with ultra-clear glass
