Comfort Slide-39535
Product Code: Comfort Slide
"""Comfort Slide Technical Specifications
Frame Profile Width: 150 mm
Wing Profile Width: 76 mm
Number of Safe Rooms: 6
Number of Wing Chambers: 5
Gasket: TPE Gray / Black
Number of Gaskets: 2
Lath: Single claw - with PCE gasket
Glass Thickness: 24, 30, 36, 44 mm
Comfort Slide PVC sliding door and window system have been designed with a different perspective from all known sliding applications, with the experience and professionalism gained from international experiences, aiming to provide more living space to the place where it is used, as well as to make it easier to use and to have a much stronger sealing. Thanks to its imported hardware specially designed for the PVC sliding system, it offers a very easy and comfortable user experience in opening and closing functions.
In the Comfort Slide PVC sliding door and window system, specially designed 149 mm wide, 6-chamber frame and 76 mm wide wing profiles are used. Thanks to these special PVC profiles with stylish design in the PVC sliding system, high heat and sound insulation values are provided.
While the Comfort Slide sliding door and window system provide maximum visibility with its aesthetic structure, it allows different styles to be reflected in architectural projects. It offers rich colour options to adapt to all kinds of decorations in the places where it is used.
GENERAL FEATURES
• Specially designed PVC profile and imported hardware
• Easy and comfortable use
• High thermal insulation
• Superior sound insulation (Acoustic Insulation)
• Large living space
• Rich colour options suitable for modern spaces
• 24-30-36-44-52 mm wide double glazing, triple glazing units and laths that allow the use of panels.
• High level of air, water and dust insulation thanks to grey and black coloured elastic gaskets that do not leave stains
• Frame profile with 149 mm width, 65 mm height and 6 chambers.
• 76 mm wide and 5-chamber wing and middle register profiles.
• Aesthetic profile-glass combination with specially designed lath profiles.
• High sealing performance thanks to the wheels running on two axes, movable guiding pins, locking elements and elastic gasket that continuously presses.
• Advantage over PVC sliding systems with ease of use and low maintenance costs.
• High level of thermal insulation even in the harshest weather conditions.
THERMAL INSULATION
• 6-chamber frame profile and 5-chamber sash and middle register profiles increase the thermal insulation performance to a higher level than similar PVC sliding door and window systems.
• Specially designed imported equipment and the ability to apply triple glass up to 52 mm minimize the heat transmission coefficient value.
• Gray or black elastic gaskets of the Comfort Slide PVC sliding system increase the thermal insulation performance.
SOUND INSULATION
• A design that will minimize the noise level, which adversely affects both adult and child health, among similar PVC sliding systems.
• Reduces the sound level to normal levels in areas with high sound levels such as highways and airports.
ENVIRONMENTAL FEATURES
EPD (Environmental Product Declaration) documents contain informative information regarding the environmental performance of building materials. It is an internationally accepted system. It has been prepared by independent organizations for white and laminated profiles, based on life cycle evaluation principles, and approved by the German IBU EPD program.
Comfort Slide PVC sliding door systems provide additional credit points in green building certification systems such as LEED, BREEAM and DGNB."""
