ASSO SLIDING BALCONY GLAZING SYSTEM-28160

Product Code: ASSO

ASSO SLIDING BALCONY GLAZING SYSTEM
• Easy installation
• Aesthetic & one-piece appearance
• Sound insulation performance
• Reduces energy consumption with the thermal insulation it provides
• Easy cleaning
• Large viewing area with minimal framing
• Smooth operating system
• Windproof system design and hardware
• Prevents direct air passage
• Registered design

Technical Specifications

• 4 track bottom-frame with 162 mm width
• 20 mm threshold height. Can be embedded to the floor up to 9mm.
• Self-drainage bottom profile design.
• Cleaner interior with pile weather seal applied at the bottom of the sash
• Vent height up to 2.700 mm
• Vent width up to 1.375 mm
• Up to 6.500 mm wide application with 8 vents (4 to 4)
• 1.quality T6 thermal processed 6060 and 6063 alloy aluminum
• 10 - 12 µm anodizing thickness
• 60 -80 µm coating thickness

Hardware

• Roller
o Special polyamide plastic with 25 mm. diameter
o Solid and rigid body structure
o Galvanized steel to increase corrosion resistance

• Locking
o Ergonomic and easy locking
o Locking with concealed door handle
o Extra safety by end to end locking

• Glass Applications
o 4 + 16 + 4 mm tempered glass
o 5 + 14 + 5 mm tempered glass
o 6 + 12 +6 mm tempered glass
o Acoustic laminated application option to reduce noise
o Low-e coating option for extra thermal insulation
o Possibility to apply 16 mm glass blinds
o Clear view with ultra-clear glass
