TGB T3 550 IF-18796

Product Code: FL SIYAH

MOTOR

Motor: 503 cc, Single Cylinder, SOHC
Ignition: ECU
Operating: Electricity
Bore and Stroke: Ø 92 X 75.6 mm
Compression Ratio: 10.2
Operation Method: Proceeds from the crank and pedal Anthem
Max Power: 28.9 kw / 6500 rpm
Max Dryer: 46.1 Nm / 5500 rpm

TRANSFER

Driving System: 4×4 Shaftlı
Gear Selection: L/H/N/R
Transfer: Automatic CVT VBelt

CHASSIS

Front Suspension: Double A-Arm
Rear Suspension: Double A-Arm
Front Brake: Disk
Rear Brake: Disk
Front Tire: AT26 X 8-14
Rear Tire: AT26 X 10-14

DIMENSIONS / CAPACITY

Wheelbase: 1280 mm
Length-Width-Height (mm):: 2155/1118/1235
Seat Height: 940 mm
Ground Clearance: 305 mm
Fuel Capacity: 18 L

OTHER

Electricity Output: DC 12V 10A 120W
