Skylight Systems-43857

Product Code: ADY-SKY

Skylight applications in modern buildings are an aesthetic solution that solves the natural lightening problem in buildings. The system consists of galvanized steel box profiles fixed to the main bearing steel construction in accordance with the architectural project and vertical and horizontal aluminum skylight profiles with condensate channels connected to them.

After placing the insulating glass selected according to the thermal insulation value, color and thickness desired on the aluminum profiles in accordance with the wedging conditions, the wick and cover assembly of the vertical elements are made then the silicone bonding and isolation process is completed.

Profile width is 65mm, and the Wall thickness options between 1,5 - 2mm are available. By using steel reinforced profiles, it is enabled to produce the skylight system. Opening sash application options and alternative sash bar mounting are possible. Discharge may be carried out by condense channel. It is as economical as it has a wide range of products.

The system is used in buildings such as hotels, hospitals, shopping malls, indoor swimming pools and sports halls.
